Buy AVYCON AVR-NT816A-24T, 16 Channels 4K UHD Digital Video Recorder, 24TB

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Options and Related Products

Capacity (TB):: Capacity (TB): 24

Avycon, AVR-NT816A-24T, 16 Ch 4K UHD Digital Video Recorder,24TB

Features:

Supports Up to 16 CH TVI/AHD/CVI/8MP/5MP/4MP/3MP/1080P/720P/WD1 video input
Supports 8CH 8MP/5MP/4MP/3MP/1080P/960P/720P IP video input
Standard H.265 high profile compression format
Intuitive and user-friendly Graphic User Interface (GUI)
Multiple Recording Modes: Manual, Scheduled, Motion, and Sensor
Playback: 8 Channels Simultaneous Playback
Search: Search by Time Slice, Time, Event (Manual, Sensor, Motion), Tag Search
Quick and Intuitive Backup via USB and Network
Pentaplex Operation: Can simultaneously allow Preview, Record, Playback, Backup and Remote Access from Different Users
Network functions such as DHCP, DDNS, PPPoE protocols supported and also access with CMS clients.
Remote Access using Internet Explorer/Safari or CVMS: Live Preview, Playback, Backup, PTZ, and System Configuration
Dual stream technology allows for High Quality Local Recordings and Standard Quality Video for Mobile and Remote Access
Allows Simultaneous Online Users to Access Device
Support PTZ Preset and Auto-Cruise, with Up to 255 Presets and 8 Cruise Paths
Support NAT Function and QR Code Scanning by Mobile Apps, Eliminating the need to Configure Port Forwarding
Powerful Mobile Apps on iOS and Android
NDAA Compliant

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

VIDEO
Video Input (Analog + IP)	Total: 24 CH Analog: 16 CH IP: 8 CH (16 CH Max. IPC Supported When Converting Analog Channels)
Output	HDMI x 1: 3840 x 2160 / 1920 x 1080 / 1280 x 1024 / 1024 x 768 VGA x 1: 1920 x 1080 / 1280 x 1024 / 1024 x 768 BNC x 1: CVBS (used as the main or spot output)
HD-Analog Input Resolution	4K / 4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 3MP / 1080P / 720P / WD1 / D1
IP Input Resolution	4K / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Incoming Bandwidth (Mbps)	32 (Max 64)
Outgoing Bandwidth (Mbps)	96
Video Compression	Standard H.264 / H.265
AUDIO
Network Input	16 Channel IPC Audio Input
Local Input	RCA x 8
Local Output	RCA x 1
2-Way Audio	Take up channel one audio input
HDMI Audio Output	Yes
Compression	G.711(U/A)
RECORDING
Resolution	4K / 4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 3MP / 1080P / 720P / WD1 / D1
Frame Rate Channels	4K at7/6fps (NTSC/PAL) / 4K Lite at15/12fps (NTSC/PAL) / 5MP at12fps (NTSC/PAL) / 5MP Lite at20fps (NTSC/PAL) / 4MP & 3MP at 15fps(NTSC) & 12fps(PAL) / 4MP Lite / 1080P / 720P / WD1 / D1 at30fps(NTSC) & 25fps(PAL)
Frame Rate	30fps(NTSC) / 25fps(PAL)
Bit Rate	32Kbps ~ 5Mbps
Record Stream	Dual Stream Recording
Mode	Manual, Timer, Motion, Smart Event
PLAYBACK
Smart Search	Highlight Colors to Display Camera Record in a certain period of time, Different Colors refer to Different Record Events
Search	Time slice / Time / Event / Tag Search / Smart Search
Function	Play, Pause, Fast Forward, Fast Rewind, Digital Zoom, etc.
Simultaneous Playback	Max 8 Channels
Live/Playback	1 Channel at 8MP / 16 Channels 1080P at 30FPS
ALARM
Alarm Input	16 Channels Local Alarm Input; IPC Alarm Input Supported
Alarm Output	4 Channels
Alarm Trigger	Manual, Motion, Exception, Smart Event
STORAGE
HDD Interface	SATA x 2, Max 18TB per HDD; e-SATA x 1
BACKUP
Network Backup	Yes
Local Backup	USB Flash Drive, USB Mobile HDD
NETWORK
Interface	RJ45 1,000 Mbps x 1
Protocol	TCP/ IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs
EXTERNAL INTERFACE
RS-485	Yes (Half-Duplex), Connect to PTZ or Keyboard
USB	USB 2.0 x 2
GENERAL
Power Supply	DC 12V/4A
Power Consumption	≤30W (Without HDD)
Working Environment	14°~122°F (-10°~50° Celcius)
Working Humidity	10% ~ 90% (Non-Condensing)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

VIDEO
Video Input (Analog + IP)	Total: 24 CH Analog: 16 CH IP: 8 CH (16 CH Max. IPC Supported When Converting Analog Channels)
Output	HDMI x 1: 3840 x 2160 / 1920 x 1080 / 1280 x 1024 / 1024 x 768 VGA x 1: 1920 x 1080 / 1280 x 1024 / 1024 x 768 BNC x 1: CVBS (used as the main or spot output)
HD-Analog Input Resolution	4K / 4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 3MP / 1080P / 720P / WD1 / D1
IP Input Resolution	4K / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Incoming Bandwidth (Mbps)	32 (Max 64)
Outgoing Bandwidth (Mbps)	96
Video Compression	Standard H.264 / H.265
AUDIO
Network Input	16 Channel IPC Audio Input
Local Input	RCA x 8
Local Output	RCA x 1
2-Way Audio	Take up channel one audio input
HDMI Audio Output	Yes
Compression	G.711(U/A)
RECORDING
Resolution	4K / 4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 3MP / 1080P / 720P / WD1 / D1
Frame Rate Channels	4K at7/6fps (NTSC/PAL) / 4K Lite at15/12fps (NTSC/PAL) / 5MP at12fps (NTSC/PAL) / 5MP Lite at20fps (NTSC/PAL) / 4MP & 3MP at 15fps(NTSC) & 12fps(PAL) / 4MP Lite / 1080P / 720P / WD1 / D1 at30fps(NTSC) & 25fps(PAL)
Frame Rate	30fps(NTSC) / 25fps(PAL)
Bit Rate	32Kbps ~ 5Mbps
Record Stream	Dual Stream Recording
Mode	Manual, Timer, Motion, Smart Event
PLAYBACK
Smart Search	Highlight Colors to Display Camera Record in a certain period of time, Different Colors refer to Different Record Events
Search	Time slice / Time / Event / Tag Search / Smart Search
Function	Play, Pause, Fast Forward, Fast Rewind, Digital Zoom, etc.
Simultaneous Playback	Max 8 Channels
Live/Playback	1 Channel at 8MP / 16 Channels 1080P at 30FPS
ALARM
Alarm Input	16 Channels Local Alarm Input; IPC Alarm Input Supported
Alarm Output	4 Channels
Alarm Trigger	Manual, Motion, Exception, Smart Event
STORAGE
HDD Interface	SATA x 2, Max 18TB per HDD; e-SATA x 1
BACKUP
Network Backup	Yes
Local Backup	USB Flash Drive, USB Mobile HDD
NETWORK
Interface	RJ45 1,000 Mbps x 1
Protocol	TCP/ IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs
EXTERNAL INTERFACE
RS-485	Yes (Half-Duplex), Connect to PTZ or Keyboard
USB	USB 2.0 x 2
GENERAL
Power Supply	DC 12V/4A
Power Consumption	≤30W (Without HDD)
Working Environment	14°~122°F (-10°~50° Celcius)
Working Humidity	10% ~ 90% (Non-Condensing)
