ACI (Automation Components), FSIG-SLM500A, 136476, Horn and Strobe, Amber

The FSIG-SLM500 Series is a multifunctional LED beacon and sounder combination developed with a multiple input technology that allows three separate levels of alarm (alert, pre-alarm, alarm) controllable via independent electric contacts. Channel 1 includes a simulated strobe (triple flash) visual signal only. Channel 2 adds an audible tone, selectable from 32 tones via dip switch, to the simulated strobe effect. Channel 3 includes a steady light and a second, unique tone selectable from 32 different tones, for a total of 64 unique tones. The volume of a selected tone is adjustable (65 dBa to 105 dBa for the highest performing tone). Its enclosure is made from a self-extinguishing polycarbonate material with high impact and UV resistance.

Applications:

Audible/Visual Alarms for Gas Detection and Alarm Systems, Visual Alarms, Audible Alarms, Equipment Status

See more product information See less

Return and Warranty

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Supply Voltage

12 to 24 VAC/VDC

Maximum Operating Current / VA Rating

12 VAC/VDC 380 mA / 6 VA / 24 VAC/VDC 460 mA / 13 VA

Input Types Accepted

Relay

Number of Channels

Three (3) / 1 Visual only / 2 Visual and Tone 1 / 3 Visual and Tone 2

Light Source

LED Array

LED Lamp Life

50,000 Hours

LED Strobe Flash Rate / Minute

85 +/- 10 Flashes (Flash Mode Only)

Flash Patterns

Three (3) / Strobe (Default), Fade, and Steady

Tones

64 options (Dip Switch selectable), three adjustable levels

Horn Decibels at 1 meter (3.28')

Adjustable from 65 to 105 dB

Operating Temperature

-22 to 131°F (-30 to 55°C)

Mounting Base Material

High Impact and UV Resistant, Self-Extinguishing Polycarbonate

Base Color

Deep Base and Wall Mount Gray

NEMA/IP Rating

Type 3R (IP65)

Product Dimensions

Strobe (Diameter x H): 3.9" (92 mm) x 2.44" (62 mm)
Deep Base (Diameter x H): 3.62" (92 mm) x 1.81" (46 mm)
Wall Mount Base (L x W x H): 4.52" (115 mm) x 3.93" (100 mm) x 2.04" (61 mm)
Protective Dome (Diameter x H): 5.015" (127 mm) x 4.359" (111 mm)

Product Details

Supply Voltage

12 to 24 VAC/VDC

Maximum Operating Current / VA Rating

12 VAC/VDC 380 mA / 6 VA / 24 VAC/VDC 460 mA / 13 VA

Input Types Accepted

Relay

Number of Channels

Three (3) / 1 Visual only / 2 Visual and Tone 1 / 3 Visual and Tone 2

Light Source

LED Array

LED Lamp Life

50,000 Hours

LED Strobe Flash Rate / Minute

85 +/- 10 Flashes (Flash Mode Only)

Flash Patterns

Three (3) / Strobe (Default), Fade, and Steady

Tones

64 options (Dip Switch selectable), three adjustable levels

Horn Decibels at 1 meter (3.28')

Adjustable from 65 to 105 dB

Operating Temperature

-22 to 131°F (-30 to 55°C)

Mounting Base Material

High Impact and UV Resistant, Self-Extinguishing Polycarbonate

Base Color

Deep Base and Wall Mount Gray

NEMA/IP Rating

Type 3R (IP65)

Product Dimensions

Strobe (Diameter x H): 3.9" (92 mm) x 2.44" (62 mm)
Deep Base (Diameter x H): 3.62" (92 mm) x 1.81" (46 mm)
Wall Mount Base (L x W x H): 4.52" (115 mm) x 3.93" (100 mm) x 2.04" (61 mm)
Protective Dome (Diameter x H): 5.015" (127 mm) x 4.359" (111 mm)
